GPS - Global Positioning System , a wonder technology developed and controlled by the U.S. Department of Defense (DOD), is making deep inroads into the consumer world as well. They require a minimum of 24 satellites orbiting at 11,000 nautical miles above the Earth. Each satellite takes 12 hours to complete an orbit. Receivers whether handheld, part of the car accessories or the more robust, highly precise military type, they calculate by extrapolating the transmitted satellite signals arriving from 4 GPS satellites to arrive at their present position in three dimensions.

GPS Technology
Each GPS satellite is outfitted with an accurate clock to let it broadcast signals coupled with a precise time message. The accuracy of the clocks at the satellites needs to be better than +- 3 nanoseconds. Precision of this order is extremely important because the receiver must determine exactly how long it takes for the signals to travel from each GPS satellite. The GPS receiver, upon receiving the signal from the satellites works out the time taken for this. The difference between the time the signal is sent and the time it is received, multiplied by the speed of light, enables the receiver to calculate the distance to the satellite.

Though it requires 3 satellites to find the latitude and longitude of the receiver's position, it needs another satellite signal to calculate the altitude. At the present level of technology, a civilian GPS receiver can determine the position to within about 300 feet which can be increased further with corrections calculated by a GPS receiver at a known fixed location.

GPS is based on a system of coordinates called the World Geodetic System 1984 (WGS 84), similar to the latitude and longitude lines we are accustomed to from our atlas maps.

GPS Tracking System
During the 'shock and awe' - Gulf War II, it is estimated that at least 90% munitions used were smart bombs - probably aided by GPS to their targets. The percentage of smart bombs used in the first Gulf war was barely 7%. Most of the coalition soldiers were equipped with GPS receivers for better coordination. GPS has undoubtedly added to the coalition forces' ability to hit military targets with unprecedented accuracy and in minimizing 'collateral damages' - unintended civilian casualties.

GPS satellites deliberately add a fraction of inaccuracy to their signals to safeguard the interests of the US. But the error introduced is known and can be readily compensated by the US military hardware so that the GPS coordinates are accurate within a few meters. But the Europeans have started an independent Galilio GPS program to reduce their dependency on the US GPS satellite Navigation System.

GPS Vehicle Tracking System
GPS has spawned a multitude of civilian applications in the few years it has been made available. The digging of the Tunnel under the English channel was synchronized using GPS receivers from Dover and Calais - both ends of the channel.

Automatic Vehicle Locating (AVL) is an offshoot of the GPS Vehicle Tracking technology - an advanced method of remote vehicle tracking and monitoring. As per the scheme of things for using the Automatic Vehicle Locating, the targeted vehicle is equipped with an AVL unit that receives signals from the GPS satellites. The GPS receiver determines its current location, speed and heading which is stored locally for eventual analysis or transmitted to a central control center using GSM - Global standard of mobile communication or other suitable wireless technology. By a combination of these technologies you can protect and monitor your mobile assets like car, truck, bike, boat or ship virtually anywhere and then locate it to within a few meters. The central tracking station monitors your vehicle 24 hours per day for unauthorized intrusion, pilfering, breakdown, accident or even for any unforeseen emergency assistance.

Alternatively any unauthorized vehicle movement or any deviation from a predefined "Geo-fence" boundary can also trigger suitable measures as seen fit by the central control system.

Marine GPS International Maritime Bureau (IMB) in the worldwide fight against piracy in the high seas advocates the use of SHIPLOC.

SHIPLOC is a small GPS Vehicle Tracking device concealed on ships which allows owners to monitor the movement of their vessels. This satellite-tracking device integrates a GPS receiver, an Argos transmitter for exact and independent ship position measurement and enough battery backup power to last for several days.

GPS Vehicle Tracking System is not for locating ships or delivering nasty payloads targeting enemy positions alone. Closer to home, GPS equipped vehicles enable you to plan your trips precisely with moving maps display. Many emergency service units are using GPS receivers to determine the position of their resources - police cars, fire trucks, or ambulances nearest to an emergency, enabling the quickest possible response in life or death situations. GPS Vehicle tracking is one of the fastest-growing GPS applications. GPS equipped fleet vehicles, public transportation systems, delivery trucks, and courier services use GPS receivers to monitor their locations, helping to reduce wasted time - improving overall efficiencies and also for Mobile Asset Recovery. Whether you are stranded in the desert or in the deep blue ocean, GPS comes to the rescue.

Mobile asset recovery - an euphemism for techniques to recover your vehicle has been made easier with GPS technology. Advances in miniaturization of electronics coupled with rapid strides in GPS technology has resulted in small devices being used for GPS vehicle tracking. These devices when fitted in vehicles enable one to keep tabs on the position of the vehicles all the time. As we have seen earlier, they can send out data to remote locations for effective surveillance and administration of mobile assets.
